ControllableModelQ

ControllableModelQ[sys]

yields True if the state-space model sys is controllable, and False otherwise.

ControllableModelQ[{sys,sub}]

yields True if the subsystem sub is controllable.

Details and Options

  • ControllableModelQ is also known as a reachable model.
  • A state-space model is said to be controllable if for any initial state and any final state there exists some control input that drives the state from to in finite time.
  • The system sys can be a standard or descriptor StateSpaceModel or AffineStateSpaceModel.
  • The following subsystems sub can be specified: » »
  • Allwhole system
    "Fast"fast subsystem
    "Slow"slow subsystem
    {λ1,}subsystem with eigenmodes
  • The "Fast" and "Slow" subsystems primarily apply to descriptor state-space models as described in KroneckerModelDecomposition.
  • The eigenmodes λi are described in JordanModelDecomposition.
  • ControllableModelQ accepts a Method option with the following settings:
  • Automaticautomatically choose the appropriate test
    "Distribution"use controllability distribution's rank
    "Gramian"use controllability Gramian's rank or positive definiteness
    "Matrix"use controllability matrix's rank
    "PBH"use PopovBelevitchHautus rank test

Examples

open allclose all

Basic Examples  (2)

A controllable system:

An uncontrollable system, since there is no way to affect the second state:

Scope  (6)

Test the controllability of a system with approximate coefficients:

Exact coefficients:

Symbolic coefficients:

Multiple-input system:

Discrete-time system:

A descriptor system:

Controllability is equivalent to controllability of both slow and fast modes (C-controllability):

Test controllability of individual eigenmodes:

The system is uncontrollable because of eigenmode :

This can be seen in the Jordan form, where there is no way to affect the third state:

Test controllability of an AffineStateSpaceModel:

If an operating point is given, controllability from is tested:

The system is controllable from a generic point:

Options  (7)

Method  (7)

By default, the controllability matrix is used for exact and symbolic systems:

The system is controllable if the ControllabilityMatrix has full rank:

The controllability Gramian is used for stable numeric systems:

The system is controllable if the ControllabilityGramian has full rank:

For the controllability Gramian, this is equivalent to it being positive definite:

The PBH rank test is used for all other numeric systems:

The system is controllable because has full rank for all :

The controllability distribution is used for input-linear systems:

For linear systems, the tests based on the controllability matrix and distribution are equivalent:

Controllability of the linearized system implies controllability of the input-linear system:

The matrix test for input linear system uses the "Matrix" method for the linearized system:

Using no control input, the system follows the drift vector field :

A system is weakly controllable if the drift vector field can also be used to move state:

Without including the drift vector field, the system is not controllable:

Applications  (5)

The position and velocities of all three masses can be controlled by the force on :

An electric circuit with the capacitor voltage and inductor current as states:

In general, the system is controllable:

However if , it is not controllable:

A unicycle with drive and steering as input:

The system is controllable, but the linearized system is not:

The parking problem:

The system is controllable, but the linearized system is not:

A rotating rigid satellite modeled using Euler's equations of motion:

Its controllability for various values of the principal moments and actuator combinations:

A grid to show the results:

If , the system is controllable with any two actuators:

If , the system is not controllable with actuators 1 and 2 or any one actuator:

If , the system is controllable only with all 3 actuators:

Properties & Relations  (7)

A diagonal system is controllable, assuming and :

With , there is no way to control the first state:

With , the first state cannot be controlled directly, but indirectly from the second state:

With , the second state cannot be controlled directly or indirectly from the first state:

Use JordanModelDecomposition to compute the canonical state-space representation above:

Compute the controllability of each mode using the "PBH" test:

For descriptor systems, KroneckerModelDecomposition is the generalization of the diagonal form:

Determine the controllability of the slow subsystem from its structure:

Compute it using the original system:

Determine the controllability of the fast subsystem:

Compute it using the original system:

If the descriptor matrix of a StateSpaceModel has full rank, there is no fast subsystem:

Hence the complete controllability of the system can be evaluated from the slow subsystem:

Controllability is invariant under a nonsingular StateSpaceTransform:

Controllability is invariant under state feedback:

Compute the state feedback using StateFeedbackGains:

The closed-loop system is also controllable:

Controllability does not mean it is output controllable (OutputControllableModelQ):

Output controllability does not imply controllability:

Possible Issues  (2)

The Gramian method is not reliable for systems that are not asymptotically stable:

The eigenvalue in the right half of the complex plane leads to instability for continuous-time systems:

For affine systems with nonzero drift, the distribution tests only for accessibility:

A random initial condition and random input signal generator:

Simulate the system 10 times with random inputs:

The system cannot be moved to the left of the initial point:
