具有代数约数的机械系统

这个质量-弹簧-阻尼系统包括一个固定顶杆，可防止第二个质量的运动.


Wolfram Language code: dynamics = {Subscript[m, 1] Subscript[x, 1]''[t] == -Subscript[b, 1] Subscript[x, 1]'[t] - Subscript[k, 1] Subscript[x, 1][t] + Subscript[b, 2](Subscript[x, 2]'[t] - Subscript[x, 1]'[t]) + Subscript[k, 2](Subscript[x, 2][t] - Subscript[x, 1][t]) + u[t], Subscript[m, 2] Subscript[x, 2]''[t] == -Subscript[b, 2](Subscript[x, 2]'[t] - Subscript[x, 1]'[t]) - Subscript[k, 1](Subscript[x, 2][t] - Subscript[x, 1][t]) + α μ[t]}; constraint = {0 == α (Subscript[x, 1][t] + Subscript[x, 2][t]) + (1 - α)μ[t]};
Wolfram Language code: pars = {Subscript[m, 1] -> 1, Subscript[m, 2] -> .5, Subscript[k, 1] -> 5, Subscript[k, 2] -> 2, Subscript[b, 1] -> .7, Subscript[b, 2] -> .3};
得出 StateSpaceModel 表示：
Wolfram Language code: msd = StateSpaceModel[Join[dynamics, constraint], {Subscript[x, 1][t], Subscript[x, 2][t], μ[t]}, {u[t]}, {Subscript[x, 1][t], Subscript[x, 2][t]}, t, DescriptorStateSpace -> True] /. pars
用 OutputResponse 模拟当顶杆锁定和开放时的系统：
Wolfram Language code: constrainedResponse = OutputResponse[msd /. α -> 1, {1}, {t, 0, 20}]; freeResponse = OutputResponse[msd /. α -> 0, {1}, {t, 0, 20}];
Wolfram Language code: Plot[constrainedResponse, {t, 0, 20}, PlotRange -> All]
Wolfram Language code: Plot[freeResponse, {t, 0, 20}, PlotRange -> All]
