Dissipation

Functions for convective heat transfer and pressure loss characteristics

Package Contents

UsersGuide

User's guide

HeatTransfer

Package for calculation of heat transfer

PressureLoss

Package for calculation of pressure loss

Utilities

Package for utilities (should not be used directly)

Information

This information is part of the Modelica Standard Library maintained by the Modelica Association.

FD2

Library description

This library contains convective heat transfer and pressure loss functions written in Modelica®. Generally the pressure loss calculations are based on incompressible fluids and total pressure difference. For devices with non changing cross sectional area, the calculated total pressure loss is equal to the static pressure difference. Geodetic pressure loss is not considered throughout the library. The functions supplied may be used separately.

The library is a non-commercial product of XRG Simulation GmbH.

Acknowledgements

The following people contributed to the Fluid.Dissipation library (alphabetical list): Jörg Eiden, Ole Engel, Nina Peci, Sven Rutkowski, Thorben Vahlenkamp, Stefan Wischhusen.

The development of the Fluid.Dissipation library was founded within the ITEA research project EuroSysLib-D by German Federal Ministry of Education and Research (promotional reference 01IS07022B). The project was started in October 2007 and ended in June 2010.

Copyright © 2007-2019, Modelica Association and contributors
