Synthetic Geometry

The Wolfram Language provides not only extensive support for analytic geometry, but also support for the symbolic representation of synthetic geometry scenes in a form suitable for automated coordinate-independent reasoning.
Scene Representation and Visualization
Synthetic geometry scenes are represented in the Wolfram Language with GeometricScene. Scenes contain parameters representing named points and quantities, as well as hypotheses consisting of symbolic 2D regions and assertions involving those parameters. Conclusions can also be added to represent geometric theorems or conjectures that those hypotheses entail. Particular instances of a scene can be represented by specifying coordinates and values for all of the parameters appearing in the scene. Multiple instances of the same scene can be represented with a single GeometricScene object.
GeometricScene[{p1,p2,},{hyp1,hyp2,}]
abstract 2D geometric scene defined by the hypotheses hypi in terms of the symbolic points pi
GeometricScene[{{p1,p2,},{k1,k2,}},hyps]
scene whose hypotheses depend on the symbolic scalar values ki
GeometricScene[{p1{x1,y1},p2{x2,y2},},hyps]
specific instance of a geometric scene with explicit coordinates for each point
GeometricScene[{{p1{x11,y11},},{p1{x21,y21},},},hyps]
collection of specific instances of a scene
GeometricScene[,,{con1,con2,}]
scene together with some conclusions coni about it
GeometricScene[{scene1,scene2,}]
combines several scene instances into one scene object
Wrapper for geometric scenes.
The simplest geometric scenes consist of only a list of points and a list of hypotheses.
Here is a scene consisting of a circumscribed triangle with one side on the diameter:
Geometric scenes can be visualized by finding a particular instance of the scene using RandomInstance.
RandomInstance[scene]
find a random instance of a scene
RandomInstance[scene,n]
find n instances
Function to find instances of a geometric scene.
Display an interactive instance of the scene:
This finds several instances of the scene:
Many 2D regions can be used as hypotheses in a geometric scene. All regions appearing in the hypotheses of a geometric scene are assumed to be nondegenerate and are displayed in instances of that scene:
AngleBisector[{p,q,r}]
infinite line bisecting the angle p q r
Circle[p,r]
circle of radius r centered at the point p
CircleThrough[{p1,p2,}]
circle passing through the points pi
Circumsphere[{p1,p2,p3}]
sphere passing through the points pi
Disk[p,r]
filled disk of radius r centered at the point p
HalfLine[{p,q}]
half-infinite line, or ray, starting at the point p and passing through the point q
InfiniteLine[{p,q}]
infinite line passing through the points p and q
Insphere[{p1,p2,p3}]
sphere tangent to the sides of the triangle p1 p2 p3
Line[{p1,p2,}]
line segment passing through the points pi, in that order
Midpoint[{p,q}]
midpoint of the line segment p q
PerpendicularBisector[{p,q}]
perpendicular bisector of the line segment p q
Point[p]
point p
Polygon[{p1,p2,}]
polygon with vertices pi
RegionBoundary[reg]
boundary of the region reg
RegionCentroid[reg]
centroid of the region reg
RegionNearest[reg,p]
point closest to the point p in the region reg
Triangle[{p,q,r}]
triangle with vertices p, q and r
TriangleCenter[{p,q,r},spec]
center of triangle p q r specified by spec
TriangleConstruct[{p,q,r},spec]
constructed geometric region defined by the triangle p q r specified by spec
2D regions supported in GeometricScene.
This is a more complex geometric scene:
Hypotheses can also be geometric assertions or equations involving geometric quantities defined on elements of the scene.
ArcLength[reg]
arc length of the region reg
Area[reg]
area of the region reg
EuclideanDistance[p,q]
Euclidean distance between the points p and q
Perimeter[reg]
perimeter of the region reg
PlanarAngle[{p,q,r}]
the measure of the angle p q r
PolygonAngle[poly,p]
vertex angle of the polygon poly at the vertex p
RegionDistance[reg,p]
distance from the point p to the region reg
RegionMeasure[reg]
measure of the region reg
SignedRegionDistance[reg,p]
signed distance from the point p to the region reg
TriangleMeasurement[{p,q,r},spec]
measurement of the triangle p q r specified by spec
Geometric quantities supported by GeometricScene.
preg
assertion that the point p is an element of the region reg
x1
assertion that the regions/quantities xi are equal
GeometricAssertion[objs,prop]
assertion that the objects objs satisfy the property prop
GeometricStep[hyps,label]
step consisting of multiple hypotheses
RegionMember[reg,p]
assertion that the point p is a member of the region reg
Assertions supported by GeometricScene.
This is the scene description for Brahmagupta's theorem:
GeometricScene also supports style:
Style[objs,opts]
specify a style
GeometricStylingRules
style all structures matching a pattern
Specifying styles within GeometricScene.
Find a perfect polygon dissection:
Construct an equilateral triangle:
Finding Conjectures
The Wolfram Language can use these scene descriptions to find conjectures that may hold for a geometric scene.
FindGeometricConjectures[scene]
find conjectures that might hold for scene
FindGeometricConjectures[{scene1,scene2,}]
find conjectures that might hold for the instances scenei
FindGeometricConjectures[scenes,patt]
find conjectures of the form patt
FindGeometricConjectures[scenes,patt,n]
find up to n conjectures
Function to find conjectures for a geometric scene.
Discover Thales's theorem:
Discover Pappus's hexagon theorem:
Discover Kosnita's theorem:
Discover the FinslerHadwiger theorem:
Geometric Reasoning
The Wolfram Language can perform logical reasoning on geometric scenes using such functions as GeometricSolveValues.
GeometricSolveValues[scene,expr]
solve for the symbolic geometric quantity expr defined by scene
GeometricSolveValues[scene,{expr1,expr2,}]
solve for multiple quanitites expr1,expr2, defined by scene
Function to solve for values in a geometric scene.
Find the area of the quadrilateral in the following scene:
Find the area of a triangle in both a general scene and a specific instance of that scene:
Reasoning on geometric objects can be done using GeometricTest.
GeometricTest[obj,prop]
test whether the geometric object obj satisfies prop
GeometricTest[{obj1,obj2,},prop]
test whether the obji satisfy prop
GeometricTest[objs,prop1,prop2,]
test whether objs satisfy each of the propi
Function to test whether geometric objects satisfy a given property.
Determine if three points are collinear:
Find conditions for three abstract points to be collinear:
Find conditions for multiple predicates to hold for a single geometric object:
