BeveledPolyhedron[poly]

通过斜切每个边给出 poly 的斜切多面体.

BeveledPolyhedron[poly,l]

按边长比 l 斜切多面体 poly.

更多信息和选项
Details and Options Details and Options
范例
基本范例
范围
应用
基本应用
多面体运算
可能存在的问题
参见
相关指南
历史
按以下格式引用：

BeveledPolyhedron

BeveledPolyhedron[poly]

通过斜切每个边给出 poly 的斜切多面体.

BeveledPolyhedron[poly,l]

按边长比 l 斜切多面体 poly.

更多信息和选项

范例

打开所有单元 关闭所有单元

基本范例  (2)

十二面体的斜切多面体：

Wolfram Language code: BeveledPolyhedron[Dodecahedron[]]
Wolfram Language code: Graphics3D[%]

给出航天飞机的斜切多面体：

Wolfram Language code: 𝒫 = BeveledPolyhedron[Polyhedron[{{-4.999492168426514, -0.6817100048065186, 0.569242000579834}, {-4.999759197235107, -0.4911530017852783, 0.8052060008049011}, {-5.349475860595703, -0.47093498706817627, 0.5660619735717773}, {-4.999759197235107, 0.491153001785278 ... }, {291, 218, 220}, {211, 259, 258}, {280, 206, 218}, {212, 258, 288}, {225, 187, 219}, {245, 197, 196}, {200, 236, 235}, {263, 196, 207}, {274, 205, 193}, {282, 210, 205}, {268, 193, 188}, {226, 219, 210}, {269, 188, 187}, {215, 288, 287}}]];

可视化：

Wolfram Language code: Graphics3D[𝒫, Boxed -> False]

范围  (4)

BeveledPolyhedron 适用于多面体：

Wolfram Language code: 𝒫 = Polyhedron[{{0, 0, 0}, {1, 0, 0}, {0, 1, 0}, {0, 0, 1}}, {{1, 2, 3}, {1, 2, 4}, {2, 3, 4}, {1, 3, 4}}];
Wolfram Language code: BeveledPolyhedron[𝒫]
Wolfram Language code: Graphics3D[%]

柏拉图体的 BeveledPolyhedron 包括 Tetrahedron：

Wolfram Language code: BeveledPolyhedron[Tetrahedron[1]]

Cube：

Wolfram Language code: BeveledPolyhedron[Cube[1]]
Wolfram Language code: Graphics3D[%]

Dodecahedron：

Wolfram Language code: BeveledPolyhedron[Dodecahedron[1]]

Octahedron：

Wolfram Language code: TruncatedPolyhedron[Octahedron[1]]

Icosahedron：

Wolfram Language code: BeveledPolyhedron[Icosahedron[1]]

支持多面体网格：

Wolfram Language code: 𝒫 = ExampleData[{"Geometry3D", "SpaceShuttle"}, "BoundaryMeshRegion"]
Wolfram Language code: BeveledPolyhedron[𝒫]
Wolfram Language code: Graphics3D[%]

按不同的长度比斜切多面体：

Wolfram Language code: 𝒫 = Polyhedron[{{0, 0, 0}, {1, 0, 0}, {0, 1, 0}, {0, 0, 1}}, {{1, 2, 3}, {1, 2, 4}, {2, 3, 4}, {1, 3, 4}}];
Wolfram Language code: Table[Graphics3D[BeveledPolyhedron[𝒫, ratio]], {ratio, {0.1, 0.2, 0.3, 0.4}}]

应用  (5)

基本应用  (3)

柏拉图体及其斜切多面体的图集：

Wolfram Language code: Grid[Table[{Graphics3D[f[1], Boxed -> False], [image], Graphics3D[BeveledPolyhedron[f[1]], Boxed -> False]}, {f, {Tetrahedron, Cube, Octahedron, Dodecahedron, Icosahedron}}]]

阿基米德体及其斜切多面体的图集：

Wolfram Language code: Multicolumn[Table[Row[{Graphics3D[f, Boxed -> False, ImageSize -> 50], [image], Graphics3D[BeveledPolyhedron[f], Boxed -> False, ImageSize -> 50]}], {f, PolyhedronData["Archimedean", "Polyhedron"]}], 2, Spacings -> 3]

斜切柏拉图体的组合：

Wolfram Language code: Table[Graphics3D[{Opacity[0.5], BeveledPolyhedron[f[1]], f[1]}, Boxed -> False], {f, {Tetrahedron, Cube, Dodecahedron}}]

阿基米德体：

Wolfram Language code: Table[Graphics3D[{Opacity[0.5], f, BeveledPolyhedron[f]}, Boxed -> False], {f, PolyhedronData["Archimedean", "Polyhedron"]}]

多面体运算  (2)

用 BeveledPolyhedron 进行多面体运算，如元运算：

Wolfram Language code: meta[poly_] := DualPolyhedron[BeveledPolyhedron[poly]]
Wolfram Language code: meta[Tetrahedron[1]]
Wolfram Language code: Graphics3D[%]

可用 TruncatedPolyhedron 算出 BeveledPolyhedron：

Wolfram Language code: bevel[poly_] := TruncatedPolyhedron[TruncatedPolyhedron[poly, 0.5]]
Wolfram Language code: bevel[Tetrahedron[1]]
Wolfram Language code: Graphics3D[%]

可能存在的问题  (2)

BeveledPolyhedron 只支持简单多面体：

Wolfram Language code: 𝒫 = Polyhedron[{{0, 0, 0}, {1, 0, 0}, {0, 1, 0}, {0, 0, 1}, {1, 0, 0}, {2, 0, 0}, {1, 1, 0}, {1, 0, 1}}, {{1, 2, 3}, {1, 2, 4}, {2, 3, 4}, {1, 3, 4}, {5, 6, 7}, {5, 6, 8}, {6, 7, 8}, {5, 7, 8}}];
Wolfram Language code: SimplePolyhedronQ[𝒫]
Wolfram Language code: BeveledPolyhedron[𝒫]

BeveledPolyhedron 可以返回退化多面体：

Wolfram Language code: BeveledPolyhedron[Polyhedron[{{-1, 0, 0}, {-1/2, -1/2, -(1/Sqrt[2])}, {-1/2, -1/2, 1/Sqrt[2]}, {-1/2, 1/2, -(1/Sqrt[2])}, {-1/2, 1/2, 1/Sqrt[2]}, {0, -1, 0}, {0, 1, 0}, {1/2, -1/2, -(1/Sqrt[2])}, {1/2, -1/2, 1/Sqrt[2]}, {1/2, 1/2, -(1/Sqrt[2])}, {1/2, 1/2, 1/Sqrt[2]}, {1, 0, 0}}, {{4, 10, 8, 2}, {3, 9, 11, 5}, {9, 6, 8, 12}, {3, 1, 2, 6}, {5, 7, 4, 1}, {11, 12, 10, 7}, {12, 11, 9}, {3, 5, 1}, {6, 9, 3}, {5, 11, 7}, {8, 10, 12}, {1, 4, 2}, {2, 8, 6}, {7, 10, 4}}]]
Wolfram Language code: RegionQ[%]
