PlotInteractivity

PlotInteractivity

is an option for graphics functions that specifies whether to allow automatic interactivity and highlighting for plots and graphics.

Details

  • PlotInteractivity can be used to control whether plots automatically include tooltips, callouts and other interactive elements.
  • Possible settings for PlotInteractivity include:
  • $PlotInteractivitysystemwide setting
    Automaticinclude interactive elements up to threshholds
    Trueinclude user-specified interactive elements
    Falsedo not include interactive elements
    Allinclude all interactive elements
    <|"User"user,"System"sys|>specify for user and system elements
  • PlotInteractivity generally affects automatic settings from plot options such as LabelingFunction and PlotHighlighting.
  • Setting PlotInteractivityFalse in Plot, ListPlot, BarChart, etc... will prevent automatic interactions, but does not affect those specified explicitly through options or wrappers.
  • With the default setting PlotInteractivityAutomatic, interactive elements are generally enabled when the complexity of the plot is lower and disabled when it is more complicated.
  • Using Show[…,PlotInteractivityFalse] will disable interactions regardless of how they were created.
  • PlotInteractivity does not affect the ability to interactively resize graphics or rotate 3D scenes.

Examples

open all close all

Basic Examples  (4)

Disable the default automatic tooltips and edge highlighting in a chart:

Disable the default automatic callouts in a plot:

Disable automatic interactive features but not those specified in the input:

Use Show to disable interactivity on graphics:

Scope  (4)

Plot highlighting is on by default:

Disable the default highlighting from the plot:

Disable the default highlighting afterward using Show:

Show is unable to add interactivity to originally static plots:
