Linear Algebra Examples

Additional functionality related to this tutorial has been introduced in subsequent versions of the Wolfram Language. For the latest information, see Matrices and Linear Algebra.

Matrix Ordering	Finite Difference Solutions
Full Rank Least Squares Solutions	Mesh Partitioning
Minimization of 1 and Infinity Norms	Matrix Functions with NDSolve

This tutorial shows a number of examples of the use of Wolfram Language for computations that involve linear algebra.

Matrix Ordering

Certain sparse matrix techniques try to reorder the matrix so that elements are grouped into blocks. The computation then works on each block using dense matrix techniques. One simple way to order a matrix into blocks involves sorting according to the sum of elements on each row. This will be demonstrated in this example.

First, generate a symmetric random sparse matrix:

In[1]:=1

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-4l6xd9

Here is a plot of the matrix:

In[6]:=6

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-ddbldf

Out[6]=6

Now compute a permutation of the matrix and then apply it to the matrix. This topic is discussed in "Matrix Permutations":

In[7]:=7

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-nnl5o7

Here is a plot of the reordered matrix; the effect of the reordering can be seen:

In[9]:=9

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-5mom19

Out[9]=9

Here is a much larger matrix with no structure and many random elements:

In[10]:=10

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-g2tkio

This is a plot of the original matrix:

In[17]:=17

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-spvxah

Out[17]=17

This plot of the reordered matrix shows that there are many rows and columns with no elements:

In[18]:=18

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-l8cmne

Out[18]=18

Full Rank Least Squares Solutions

Solving a matrix equation is one of the key problems of matrix computation; techniques for solving it are discussed under "Solving Linear Systems". If is an × matrix, this is a set of linear equations in unknowns. If , there are more equations than unknowns and the system is overdetermined. A general technique for finding least squares solutions is given under "Least Squares Solutions". This example will show some different techniques for finding approximate solutions to overdetermined systems for full rank matrices.

Note that all the example solutions in this section would work just as well if they were given sparse matrices as input.

Least Squares Cholesky

This technique uses a Cholesky decomposition to find a least squares solution. If a matrix has full rank, the solution can be found in the following way.

These steps can be placed into a Wolfram Language function as follows:

In[1]:=1

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-zcin9r

The function can be applied as follows:

In[2]:=2

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-rz0bhp

Out[4]=4

The solution is close to satisfying the equation:

In[5]:=5

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-cxfwbq

Out[5]=5

This compares the solution to that from PseudoInverse:

In[6]:=6

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-xqb2sl

Out[6]=6

This technique is fast, but is less accurate because it computes .

This computes 1-, 2-, and

-norms for the solution that was found:

In[7]:=7

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-6moye0

Out[7]=7

Least Squares QR

When is full rank, a more accurate way to solve the problem is to use the QR decomposition as follows.

A Wolfram Language program to find the solution is as follows:

In[1]:=1

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-6qmgho

The solution for this problem is very similar to the Cholesky solution:

In[2]:=2

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-j9ldjv

Out[4]=4

The QR decomposition solution can be more expensive than the Cholesky approach, but it is more accurate. An example that demonstrates the difference in accuracy is shown:

In[5]:=5

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-oyrcf3

This shows how close the Cholesky solution is when using the 2-norm:

In[9]:=9

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-7qno4e

Out[9]=9

This shows how close the QR solution is when using the 2-norm. It can be seen that the QR solution is a better approximation:

In[10]:=10

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-l2vrlg

Out[10]=10

Minimization of 1 and Infinity Norms

Many techniques for finding approximate solutions for the matrix equation when it is overdetermined (i.e., when ) work by minimizing the 2-norm. This is because of certain advantages that make it computationally tractable. One reason is that the function

is differentiable and differentiation is a linear operation. Thus, a linear system can be formed that finds the minimizing solutions. Another reason is that the 2-norm is preserved under orthogonal transformations. This means that a range of equivalent problems can be formed, which may be easier to solve.

However, there are other solutions that can be found by minimizing other norms, such as the 1-norm or the -norm. These may be more desirable in the particular context because they may find solutions that maintain important properties relevant to the individual problem. In this example techniques are shown to find approximate solutions that minimize these norms; both will use a method to find minimum values of constrained linear problems; typically this is known as linear programming.

In Wolfram Language, linear programming is provided by the function LinearProgramming. This can solve the linear programming problem for the different types of numbers that Wolfram Language supports: integers and rational numbers, as well as machine-precision approximate real and arbitrary-precision approximate real numbers. In addition, it provides techniques that are suitable for minimizing extremely large systems by means of an interior point method.

The solutions given in this section are suitable for dense matrix input. It would be straightforward to modify them for sparse matrix input; this would be necessary to take full advantage of the interior point linear programming technique.

Note that the techniques in this section could be extended to add other constraints on the solution.

One-Norm Minimization

Minimizing the 1-norm involves finding the value of that minimizes the following.

This is done by forming new variables and finding the minimum.

This is implemented with the following program:

In[1]:=1

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-5j5zg8

This finds the solution:

In[2]:=2

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-251501

Out[4]=4

Here 1-, 2-, and

-norms are computed for the solution that was found:

In[5]:=5

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-tqprxo

Out[5]=5

Infinity-Norm Minimization

Minimizing the -norm is similar to minimizing the 1-norm. It involves finding the value of that minimizes the following.

This is done by forming new variables and finding the minimum.

This is implemented with the following program:

In[1]:=1

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-iobqvv

This finds the solution:

In[2]:=2

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-3blxyn

Out[4]=4

Here 1-, 2-, and

-norms are computed for the solution that was found:

In[5]:=5

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-3udfsr

Out[5]=5

Finite Difference Solutions

One way to solve partial differential equations is to form a spatial discretization and solve them with finite differences. This example considers a basic finite difference solution for the Poisson equation on a unit square.

This sets up the problem for an 80×80 grid with

. An abbreviated form of the variable matrix is printed out:

In[1]:=1

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-y5ocd

This is the finite difference formula for the differential operator:

In[9]:=9

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-rh9ctl

In this step the application of the finite difference formula to the variable matrix is made. The boundary conditions are incorporated by allowing an overhang of one variable with a coefficient of zero around the boundary:

In[10]:=10

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-716b1n

Here equations for the solutions on the grid are formed:

In[11]:=11

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-2cyq4i

The approximate solution to the Poisson equation will be found by solving these equations. One way to solve the equations is to use Solve, which will recognize the equations as linear and sparse and accordingly use a sparse matrix solver. Another method that also gives you the possibility of solving additional Poisson problems is to construct a matrix from the equations. The matrix represents the linear operator when the grid is flattened into a vector:

In[12]:=12

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-u64hzd

Out[12]=12

Now the solution is quickly found using LinearSolve:

In[13]:=13

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-bd1lax

Out[13]=13

This repartitions the solution to restore the original structure:

In[14]:=14

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-ffloes

This makes a contour plot of the solution:

In[15]:=15

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-ma9xz7

Out[15]=15

If you wanted to solve several Poisson equations with the same geometries but different right-hand functions, you could compute a factorization of the matrix and use it repeatedly. The way that Wolfram Language allows you to repeat the factorization is described under "Saving the Factorization":

In[16]:=16

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-d7uiox

Out[16]=16

Now you just need to give it a vector representing the function Cos[6x²+3y²] on the grid:

In[17]:=17

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-89ybfg

This passes the vector to the factorization, thereby finding the solution:

In[19]:=19

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-lduu55

Out[19]=19

It should be noted that this solution is only available at discrete points in the interior of the region. It does not include the value on the boundary or at other points in the interior. If the solution was to be used for other computational purposes this might be a limitation. PadLeft and PadRight could be used to add the boundary value and Interpolation used to generate an interpolating function for the region:

In[20]:=20

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-ft1bng

Out[22]=22

This uses Plot3D to plot the solution:

In[23]:=23

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-rslwwh

Out[23]=23

Now the solution can be computed at any position in the region:

In[24]:=24

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-ji3x0u

Out[24]=24

Mesh Partitioning

This example demonstrates a practical use for extreme eigenvalues. The aim is to partition the vertices of a mesh/graph into two subdomains, with each part having roughly equal numbers of vertices and with the partition cutting through as few edges as possible. (An edge is cut if its two vertices lie in each of the two subdomains.) One way to partition a graph is to form the Laplacian and use its Fiedler vector (the eigenvector that corresponds to the second smallest eigenvalue) to order the vertices. There are more efficient algorithms for graph partitioning that do not require the calculation of the eigenvector, but the approach using Fiedler remains an important one.

Data

This is the data for the coordinates of the vertices:

In[1]:=1

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-g3x3e0

This is a list of triangles that forms the mesh:

In[2]:=2

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-h808dw

Plotting the Mesh

To plot the mesh, simply plot each of the triangles:

In[3]:=3

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-oilgpm

Out[8]=8

The Laplacian

A Laplacian of a graph, , is an × sparse matrix, with the number of vertices in the graph. The entries of are mostly zero, except that the diagonals are positive integers that correspond to the degree of the vertex, where the degree is the number of vertices linked to the vertex. In addition, if two vertices, and , are joined by an edge, the entry is -1.

For the mesh here, the off-diagonals are given by the sparse array

In[9]:=9

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-ppcucb

Out[10]=10

Each diagonal in a row is the negated sum of the off-diagonals. Thus the diagonal part of matrix is as follows:

In[11]:=11

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-kzkpd6

Out[11]=11

Therefore, the Laplacian is given as shown here:

In[12]:=12

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-yawj3p

Out[12]=12

This visualizes the matrix:

In[13]:=13

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-vxvkyl

Out[13]=13

The Fiedler Vector

The sum of each row is zero, therefore the Laplacian matrix is positive semi-definite with a zero eigenvalue. The eigenvector corresponding to the second smallest eigenvalue is called the Fiedler vector.

This calculates the two smallest eigenvalues and eigenvectors:

In[14]:=14

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-q3dblg

One of these eigenvalues is zero:

In[15]:=15

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-pzhsnz

Out[15]=15

Partitioning the Nodes

Now use the Fiedler eigenvector to generate an ordering of vertices and form two groups of vertices: domain1 and domain2:

In[16]:=16

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-qjlmgt

This sets the colors of vertices in domain1 as Hue[0.] (red) and vertices in domain2 as Hue[0.75] (blue):

In[19]:=19

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-pa0aka

This plots the partition. As can be seen, the partitions avoided the very dense part of the mesh, and each subdomain is nicely connected:

In[21]:=21

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-149trl

Out[23]=23

The number of edges cut by the partition can be calculated as follows:

In[24]:=24

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-qhgoap

Out[26]=26

Matrix Functions with NDSolve

One of the important features of many of Wolfram Language's numerical solvers is that they work for vector and matrix input. Typically this is used to solve coupled systems of equations, but it can be used to solve matrix specific problems. One example will be given here that uses the numerical differential equation solver, NDSolve, to find parametrized solutions to matrix functions.

Here is a 3×3 matrix:

In[1]:=1

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-vc98we

The exponential function is the solution of the differential equation.

This can be demonstrated by solving the equation symbolically:

In[3]:=3

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-zjgsq2

Out[3]=3

The matrix exponential Exp[A t] can be found by forming a matrix equation and solving with NDSolve. The solution here is valid for

In[4]:=4

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-l9dz8d

Out[5]=5

The solution is a function that will return the matrix function Exp[A t] for a range of t. If t is 0.0, the identity matrix is returned:

In[6]:=6

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-kut4zo

This demonstrates that Exp[A]:Exp[A ]=Exp[2A]:

In[7]:=7

✖

https://wolfram.com/xid/0w5lnrqgqk9l9s-im00b5

Wolfram Language already has a function for computing the exponential of a function, MatrixExp. This can be compared with the solution that was computed:

In[9]:=9
