Built-in Mathematica Symbol

BarChart3D

BarChart3D[{y₁, y₂, ...}]
makes a 3D bar chart with bar lengths y₁, y₂, ....

BarChart3D[{..., w_i[y_i, ...], ..., w_j[y_j, ...], ...}]
makes a 3D bar chart with bar features defined by the symbolic wrappers w_k.

BarChart3D[{data₁, data₂, ...}]
makes a 3D bar chart from multiple datasets data_i.

	y_i	a pure bar value
	w_i[y_i,...]	a bar with value y_i and wrapper w_i
	form_i->m_i	a bar form with metadata m_i

Data not given in these forms is taken to be missing, and typically yields a gap in the 3D bar chart.

	{e₁,e₂,...}	list of elements with or without wrappers
	w[{e₁,e₂,...},...]	wrapper applied to a whole dataset
	w[{data₁,data₁,...},...]	wrapper applied to all datasets

	Annotation[e,label]	provide an annotation
	Button[e,action]	define an action to execute when the element is clicked
	EventHandler[e,...]	define a general event handler for the element
	Hyperlink[e,uri]	make the element act as a hyperlink
	Labeled[e,...]	display the element with labeling
	Legended[e,...]	include features of the element in a chart legend
	Mouseover[e,over]	make the element show a mouseover form
	PopupWindow[e,cont]	attach a popup window to the element
	StatusArea[e,label]	display in the status area when the element is moused over
	Style[e,opts]	show the element using the specified styles
	Tooltip[e,label]	attach an arbitrary tooltip to the element

	Top,Bottom,Left,Right,Center, Front,Back	positions within bars
	Above, Below, Before, After	positions outside bars
	Axis	on the bar origin axis
	{{b_x,b_y,b_z},{l_x,l_y}}	scaled position {l_x, l_y} in the label at scaled position {b_x, b_y, b_z} in the bar

BarChart3D has the same options as Graphics3D with the following additions and changes:

BarOrigin	Bottom	origin of bars
Axes	True	whether to draw axes
BarSpacing	Automatic	spacing between bars
Boxed	False	whether to draw a bounding box
ChartBaseStyle	Automatic	overall style for bars
ChartElements	Automatic	graphics to use for each of the bars
ChartElementFunction	Automatic	how to generate raw graphics for bars
ChartLabels	None	labels for data elements and datasets
ChartLayout	Automatic	overall layout to use
ChartLegends	None	legends for data elements and datasets
ChartStyle	Automatic	style for bars
ColorFunction	Automatic	how to color bars
ColorFunctionScaling	True	whether to normalize arguments to ColorFunction
FaceGrids	Automatic	grid lines to draw on the bounding box
LabelingFunction	Automatic	how to label bars
LegendAppearance	Automatic	overall appearance of legends
Lighting	"Neutral"	simulated light sources to use
PerformanceGoal	$PerformanceGoal	aspects of performance to try to optimize
ViewPoint	Automatic	viewing position

Possible settings for ChartLayout include "Grouped", "Stacked", "Stepped" and "Percentile".

The arguments supplied to ChartElementFunction are the bar region {{x_min, x_max}, {y_min, y_max}, {z_min, z_max}}, the data values y_i, and metadata {m₁, m₂, ...} from each level in a nested list of datasets.

A list of built-in settings for ChartElementFunction can be obtained from ChartElementData["BarChart3D"].

With the setting ChartElements->g, the graphic g will be used to form pictorial bars consisting of stretched versions of g.

Style and other specifications from options and other constructs in BarChart3D are effectively applied in the order ChartStyle, ColorFunction, Style and other wrappers, ChartElements and ChartElementFunction, with later specifications overriding earlier ones.
