BezierCurve

BezierCurve[{pt1,pt2,…}]

图形基元，表示控制点为 pti 的贝塞尔曲线.

更多信息和选项

  • BezierCurve 也被称为贝塞尔样条曲线或伯恩斯坦多项式曲线.
  • BezierCurve 通常用于表示字体和矢量图形中的曲线路径.
  • 控制点 pi 是诸如 {x,y} 或 {x,y,z} 这样的普通坐标.
  • BezierCurve[{p1,p2,p3,p4}] 表示一条简单的三次贝塞尔曲线.
  • 具有超过四个控制点的 BezierCurve 表示一条复合三次贝塞尔曲线.
  • 通过使用多个贝塞尔线段，复合曲线可表示更多样化的形状.
  • BezierCurve 既可用作几何区域，也可用作图形基元.
  • 在图形中，点 pi 可以是 Scaled、Offset、ImageScaled 和 Dynamic 表达式.
  • 图形渲染受诸如 Thickness、Dashing、JoinForm、CapForm 以及颜色等指令的影响.
  • 可给出下列选项：
  • SplineDegree Automatic多项式基的次数
    SplineClosed False是否使曲线闭合
  • 选项 SplineDegree->d 指定底层多项式基的最大次数为 d.
  • SplineDegree->d 时，有 d+1 个控制点的 BezierCurve 产生一个简单的 d 次 Bézier 曲线. 控制点较少时，产生一个较低次数的曲线. 控制点较多时，则产生一个复合 Bézier 曲线.
  • 具有 n 个控制点的 d 次 BezierCurve 表示区域 {}，其中，B_(k,d) 是第 k 个 d 次 Bernstein 基函数.

范例

打开所有单元 关闭所有单元

基本范例  (3)

二维图形中的一个 Bézier 曲线和它的控制点：

Wolfram Language code: pts = {{0, 0}, {1, 1}, {2, -1}, {3, 0}};
Wolfram Language code: Graphics[{BezierCurve[pts], Dashed, Gray, Line[pts], Red, Point[pts]}]

三维图形中的一个 Bézier 曲线和它的控制点：

Wolfram Language code: pts = {{0, 0, 0}, {1, 1, 1}, {2, -1, 1}, {3, 0, 2}}
Wolfram Language code: Graphics3D[{BezierCurve[pts], Dashed, Gray, Line[pts], Red, Point[pts]}]

弧长和界限：

Wolfram Language code: reg = BezierCurve[{{0, 0}, {1, 1}, {2, -1}}];
Wolfram Language code: ArcLength[reg]
Wolfram Language code: RegionBounds[reg]

用 Bézier 曲线构建的字母 "S"：

Wolfram Language code: Graphics[{LinearGradientFilling[{StandardRed, StandardYellow}], EdgeForm[Thick], FilledCurve[BezierCurve[IconizedObject[«[image]»]]]}]

范围  (26)

基本用法  (4)

模拟线性曲线：

Wolfram Language code: Graphics[BezierCurve[{{0, 0}, {2, 1}}]]

非线性曲线：

Wolfram Language code: Graphics[BezierCurve[{{-3, 0}, {6, 5}, {-6, -5}, {3, 0}}]]

模拟开放曲线：

Wolfram Language code: Graphics[BezierCurve[{{-1, 3}, {-2, 0}, {2, 0}, {1, 3}}]]

闭合曲线：

Wolfram Language code: Graphics[BezierCurve[{{0, 1}, {-1, 0}, {1, 0}}, SplineClosed -> True]]

模拟填充曲线：

Wolfram Language code: Graphics[{FilledCurve[BezierCurve[IconizedObject[«[image]»]]]}]

未填充曲线：

Wolfram Language code: Graphics[BezierCurve[IconizedObject[«[image]»]]]

摘要框：

Wolfram Language code: BezierCurve[{{-3, 0}, {6, 5}, {-6, -5}, {3, 0}}]

指定  (4)

二次贝塞尔曲线需要三个控制点：

Wolfram Language code: Graphics[BezierCurve[{{-1, 0}, {0, 2}, {1, 0}}]]
Wolfram Language code: Graphics3D[BezierCurve[{{-1, 0, 0}, {0, 2, 1}, {1, 0, 0}}]]

三次贝塞尔曲线需要四个控制点：

Wolfram Language code: Graphics[BezierCurve[{{-3, 0}, {6, 5}, {-6, -5}, {3, 0}}]]
Wolfram Language code: Graphics3D[BezierCurve[{{-3, -1, 0}, {6, 5, 5}, {-6, -5, -5}, {3, 1, 0}}]]

通常，一条简单的次数为 d 的贝塞尔样条曲线需要 (d+1) 个控制点：

Wolfram Language code: pts = {{0, 0}, {(1/3), (Sqrt[3]/2)}, {(2/3), (Sqrt[3]/2)}, {1, 0}, {(4/3), (Sqrt[3]/2)}, {(5/3), (Sqrt[3]/2)}, {2, 0}};
Wolfram Language code: deg = Length[pts] - 1;
Wolfram Language code: BezierCurve[pts, SplineDegree -> deg]
Wolfram Language code: Graphics[%]

控制点越少，生成的曲线次数越低：

Wolfram Language code: BezierCurve[Take[pts, 4], SplineDegree -> deg]
Wolfram Language code: Graphics[%]

通过更多的控制点，可以生成一条复合贝塞尔曲线：

Wolfram Language code: BezierCurve[pts, SplineDegree -> 3]
Wolfram Language code: Graphics[%]

开放的贝塞尔曲线：

Wolfram Language code: Graphics[{BezierCurve[{{-2, 0}, {-1, 2}, {1, 2}, {2, 0}}]}]

闭合的：

Wolfram Language code: Graphics[{BezierCurve[{{-2, 0}, {-1, 2}, {1, 2}, {2, 0}}, SplineClosed -> True]}]

图形  (12)

彩色的曲线：

Wolfram Language code: Table[Graphics[{c, BezierCurve[{{0, 0}, {1, 2}, {3, 2}, {4, 0}}]}], {c, {RGBColor[0.93, 0.27, 0.27], RGBColor[0.14, 0.8, 0.14], RGBColor[0.4, 0.6, 1]}}]

不同粗细的贝塞尔曲线：

Wolfram Language code: Table[Graphics[{Thickness[i], BezierCurve[{{0, 0}, {1, 2}, {3, 2}, {4, 0}}]}], {i, {Tiny, Small, Medium, Large}}]
Wolfram Language code: Table[Graphics[{t, BezierCurve[{{0, 0}, {1, 2}, {3, 2}, {4, 0}}]}], {t, {Thin, Thick}}]

相对于 PlotRange 缩放的粗细：

Wolfram Language code: Table[Graphics[{Thickness[i], BezierCurve[{{0, 0}, {1, 2}, {3, 2}, {4, 0}}]}], {i, {.005, .05, .1}}]

以打印阵点表示的粗细：

Wolfram Language code: Table[Graphics[{AbsoluteThickness[i], BezierCurve[{{0, 0}, {1, 2}, {3, 2}, {4, 0}}]}], {i, {1, 5, 10}}]

虚线：

Wolfram Language code: Table[Graphics[{Dashing[i], BezierCurve[{{0, 0}, {1, 2}, {3, 2}, {4, 0}}]}], {i, {Tiny, Small, Medium, Large}}]
Wolfram Language code: Table[Graphics[{d, BezierCurve[{{0, 0}, {1, 2}, {3, 2}, {4, 0}}]}], {d, {Dotted, Dashed, DotDashed}}]

Opacity 指定曲线的透明度：

Wolfram Language code: Table[Graphics[{Opacity[o], BezierCurve[{{0, 0}, {1, 2}, {3, 2}, {4, 0}}]}], {o, {0.1, 0.5, 0.9}}]

在用作 FilledCurve 的边界时，可通过 EdgeForm 指定曲线的样式：

Wolfram Language code: Graphics[{EdgeForm[{StandardBlue, Thick}], Opacity[0.1], FilledCurve[BezierCurve[{{0, 0}, {1, 2}, {3, 2}, {4, 0}}]]}]

BezierCurve 可用作二维图形中 Arrow 的曲线：

Wolfram Language code: Graphics[{Arrowheads[Large], Arrow[BezierCurve[{{0, 0}, {1, 2}, {3, 2}, {4, 0}}]]}]

3D：

Wolfram Language code: Graphics3D[{Arrowheads[Large], Arrow[BezierCurve[{{0, 0, 0}, {1, 2, 2}, {3, 2, 02}, {4, 0, 0}}]]}]

在三维空间中，BezierCurve 可用作 Tube 的曲线：

Wolfram Language code: Graphics3D[{Tube[BezierCurve[{{0, 0, 0}, {1, 2, 2}, {3, 2, 02}, {4, 0, 0}}], 0.1]}]

带有 Arrow 的 Tube：

Wolfram Language code: Graphics3D[{Arrowheads[0.2], Arrow[Tube[BezierCurve[{{0, 0, 0}, {1, 2, 2}, {3, 2, 02}, {4, 0, 0}}], 0.1]]}]

BezierCurve 可用在 GraphicsComplex 中：

Wolfram Language code: Graphics[{GraphicsComplex[{{0, 0}, {1, 2}, {3, 2}, {4, 0}}, BezierCurve[{1, 2, 3, 4}]]}]

默认情况下，控制点被假定为在世界坐标系中：

Wolfram Language code: pts = {{0, 0}, {(1/4), 1}, {(3/4), 1}, {1, 0}};
Wolfram Language code: Table[Graphics[{BezierCurve[pts]}, Frame -> True, PlotRange -> {{0, pr}, {0, pr}}], {pr, {1, 2, 4}}]

用 Scaled 来指定相对于 PlotRange 的控制点：

Wolfram Language code: Table[Graphics[{BezierCurve[Map[Scaled, pts]]}, Frame -> True, PlotRange -> {{0, pr}, {0, pr}}], {pr, {4, 8, 16}}]

用 ImageScaled 来指定相对于整个二维图像区域的控制点：

Wolfram Language code: Table[Graphics[{BezierCurve[Map[ImageScaled, pts]]}, Frame -> True, PlotRange -> {{0, pr}, {0, pr}}], {pr, {4, 8, 16}}]

用 Offset 设置二维控制点的绝对偏移量：

Wolfram Language code: pts = {{0, 0}, {(1/4), 1}, {(3/4), 1}, {1, 0}};
Wolfram Language code: offsets = {{-80, 0}, {0, 0}, {80, 0}};
Wolfram Language code: Graphics[{Table[BezierCurve[Map[Offset[offset, #]&, pts]], {offset, offsets}]}, PlotRange -> {{-1.4, 2.4}, {-0.1, 1}}, ImageSize -> 250]

控制点可以是 Dynamic：

Wolfram Language code: DynamicModule[{z = 0, pts}, pts = {{Dynamic[{0, z}], {1, 2}, {3, 2}, {4, 0}}}; {Slider[Dynamic[z], {0, 4}], Graphics[{BezierCurve[pts]}]}]

区域  (6)

嵌入维度：

Wolfram Language code: reg = BezierCurve[{{Subscript[c, 1], Subscript[c, 2]}, {Subscript[c, 3], Subscript[c, 4]}, {Subscript[c, 5], Subscript[c, 6]}}];
Wolfram Language code: RegionEmbeddingDimension[reg]

几何维度：

Wolfram Language code: RegionDimension[reg]

点成员测试：

Wolfram Language code: reg = BezierCurve[{{0, 0}, {1, 2}, {3, 2}, {4, 0}}];
Wolfram Language code: {RegionMember[reg, {0, 0}], RegionMember[reg, {0, 1}]}

弧长：

Wolfram Language code: reg = BezierCurve[{{0, 0}, {1, 2}, {2, 0}}];
Wolfram Language code: {ArcLength[reg], RegionMeasure[reg]}

形心：

Wolfram Language code: c = RegionCentroid[reg]
Wolfram Language code: Show[Region[reg], Graphics[{LightDarkSwitched[Black, White], Point[c]}]]

与点的距离：

Wolfram Language code: reg = BezierCurve[{{-1, -1}, {0, 1}, {1, -1}}];
Wolfram Language code: {RegionDistance[reg, {-1, -1}], RegionDistance[reg, {2, 2}]}

可视化等距线：

Wolfram Language code: Show[Region[reg], ContourPlot[Evaluate@RegionDistance[reg, {x, y}], {x, -4, 4}, {y, -4, 3}, Contours -> {1, 2, 3}, ...], Frame -> True]

到点的有符号距离：

Wolfram Language code: reg = BezierCurve[{{-1, -1}, {0, 1}, {1, -1}}];
Wolfram Language code: {SignedRegionDistance[reg, {-1, -1}], SignedRegionDistance[reg, {2, 2}]}

贝塞尔曲线是有边界的：

Wolfram Language code: reg = BezierCurve[{{-1, -1}, {0, 1}, {1, -1}}];
Wolfram Language code: BoundedRegionQ[reg]

获取其范围：

Wolfram Language code: bb = CoordinateBoundingBox[reg]
Wolfram Language code: Show[Region[reg], Graphics[{Opacity[0.1], EdgeForm[Dashed], Cuboid@@bb}]]

选项  (3)

SplineDegree  (2)

默认情况下，一个具有 4 个或更多控制点的 BezierCurve 将使用 3 次曲线：

Wolfram Language code: pts = Table[{i, (-1) ^ i}, {i, 10}];
Wolfram Language code: {BezierCurve[Take[pts, 4]], BezierCurve[Take[pts, 10]]}

控制点较少时，会使用较低的次数：

Wolfram Language code: {BezierCurve[Take[pts, 2]], BezierCurve[Take[pts, 3]]}

用 SplineDegree 指定应使用较低的次数：

Wolfram Language code: BezierCurve[pts, SplineDegree -> 1]

更高的次数：

Wolfram Language code: BezierCurve[pts, SplineDegree -> 9]

对于有 n 个控制点的 BezierCurve，当指定次数 d 满足 d < n-1 时，将生成一条复合贝塞尔曲线：

Wolfram Language code: pts = Table[{i, 2(-1) ^ i}, {i, 7}];
Wolfram Language code: Region[BezierCurve[pts, SplineDegree -> #]]& /@ {2, 3, 4}

SplineClosed  (1)

默认情况下，曲线是开放的：

Wolfram Language code: pts = {{0, -(1/2)}, {(Sqrt[3]/2), -(1/2)}, {(Sqrt[3]/2), (1/2)}, {0, (1/2)}, {-(Sqrt[3]/2), (1/2)}, {-(Sqrt[3]/2), -(1/2)}};
Wolfram Language code: Graphics[{BezierCurve[pts]}]

用 SplineClosed 使曲线闭合：

Wolfram Language code: Graphics[{BezierCurve[pts, SplineClosed -> True]}]

这相当于将第一个控制点附加到数组的末尾：

Wolfram Language code: Graphics[{BezierCurve[Append[pts, First[pts]]]}]

应用  (6)

字体  (4)

字体通常使用贝塞尔曲线来定义字形轮廓：

Wolfram Language code: Graphics[BezierCurve[#]]& /@ {IconizedObject[«[image]»], IconizedObject[«[image]»], IconizedObject[«[image]»]}

指定不同样式的边：

Wolfram Language code: glyph = FilledCurve[BezierCurve[IconizedObject[«[image]»]]];
Wolfram Language code: Graphics[{EdgeForm[#], FaceForm[], glyph}]& /@ {Thick, Dashed, StandardRed}

不同的填充样式：

Wolfram Language code: Graphics[{#, glyph}]& /@ {StandardBlue, LinearGradientFilling[{StandardRed, StandardYellow}], HatchFilling[0, 1, 3]}

视觉效果：

Wolfram Language code: Graphics[{#, glyph}, PlotRangePadding -> Scaled[0.05]]& /@ {DropShadowing[], Haloing[StandardYellow, 0, 5], Blurring[]}

用 RegionDilation 来模拟不同的字体粗细：

Wolfram Language code: glyph = FilledCurve[Map[List, BezierCurve /@ {IconizedObject[«[image]»], IconizedObject[«[image]»], IconizedObject[«[image]»]}]];
Wolfram Language code: Table[Graphics[RegionDilation[glyph, t]], {t, {0, 2}}]

Haloing：

Wolfram Language code: Table[Graphics[{Haloing[ThemeColor["Foreground"], t], glyph}, PlotRangePadding -> Scaled[.1]], {t, {0, 5}}]

用 ShearingTransform 模拟不同的字体倾斜效果：

Wolfram Language code: glyph = FilledCurve[Map[List, BezierCurve /@ {IconizedObject[«[image]»], IconizedObject[«[image]»], IconizedObject[«[image]»]}]];
Wolfram Language code: Table[Graphics[GeometricTransformation[glyph, ShearingTransform[θ , {1, 0}, {0, 1}]]], {θ, {0, 20Degree}}]

向量图形  (2)

用 BezierCurve 来绘制由自由曲线路径组成的形状：

Wolfram Language code: Graphics[{BezierCurve[IconizedObject[«[image]»]]}]

用 FilledCurve 来设置形状内部的样式：

Wolfram Language code: Graphics[{LinearGradientFilling[{Hue[0.333, 0.8250000000000001, 0.639], Hue[0.169, 1, 0.9530000000000001]}, Top], EdgeForm[Thick], FilledCurve[BezierCurve[IconizedObject[«[image]»]]]}]

用多条贝塞尔曲线绘制更复杂的形状：

Wolfram Language code: curves = BezierCurve /@ {IconizedObject[«[image]»], IconizedObject[«[image]»], IconizedObject[«[image]»], IconizedObject[«[image]»], IconizedObject[«[image]»]};
Wolfram Language code: Graphics[curves]

设置内部的样式：

Wolfram Language code: Graphics[{FilledCurve[List /@ curves], RGBColor[0.9058724017188509, 0.13725482819401516, 0., 1.], FilledCurve[curves[[1]]]}]

属性和关系  (14)

次数为 1 的 BezierCurve 等价于 Line：

Wolfram Language code: pts = {{0, -1}, {2, 1}, {4, -1}, {6, 1}};
Wolfram Language code: Graphics /@ {BezierCurve[pts, SplineDegree -> 1], Line[pts]}

BezierCurve 是 BSplineCurve 的特例：

Wolfram Language code: pts = {{-3, 0}, {6, 5}, {-6, -5}, {3, 0}};
Wolfram Language code: Graphics /@ {BezierCurve[pts], BSplineCurve[pts]}

用 RegionConvert 获取等价的 BSplineCurve：

Wolfram Language code: RegionConvert[BezierCurve[pts], "Spline"]

BezierSurface 是 BezierCurve 的高维形式，它接受一个控制点矩形数组：

Wolfram Language code: pts = (⁠| | | | | | ---------- | ----------- | ----------- | ----------- | | {0, 0, 7} | {0, 3, 10} | {0, 7, 10} | {0, 10, 7} | | {3, 0, 10} | {3, 3, 14} | {3, 7, 14} | {3, 10, 10} | | {7, 0, 10} | {7, 3, 14} | {7, 7, 14} | {7, 10, 10} | | {10, 0, 7} | {10, 3, 10} | {10, 7, 10} | {10, 10, 7} |⁠);
Wolfram Language code: Graphics3D[BezierSurface[pts]]

下面的 BezierSurface 的边界由四条贝塞尔曲线构成：

Wolfram Language code: bc = Map[BezierCurve, {pts[[1]], pts[[-1]], pts[[All, 1]], pts[[All, -1]]}];
Wolfram Language code: Graphics3D[{BezierSurface[pts], Thick, StandardRed, bc}]

BezierSurface 上的所有等参曲线都是有效的贝塞尔曲线：

Wolfram Language code: uc = Table[BezierCurve[Map[#[u]&, Map[BezierFunction, pts]]], {u, 0, 1, 1 / 5}]; vc = Table[BezierCurve[Map[#[v]&, Map[BezierFunction, Transpose[pts]]]], {v, 0, 1, 1 / 5}];
Wolfram Language code: Graphics3D[{BezierSurface[pts], Thick, RGBColor[0.14, 0.8, 0.14], uc, RGBColor[0.4, 0.6, 1], vc}]

可用一条复合的 BezierCurve 很好地近似一个 Circle：

Wolfram Language code: Region /@ {BezierCurve[IconizedObject[«[image]»]], Circle[]}

近似误差很小：

Wolfram Language code: RegionHausdorffDistance@@%

BezierCurve 总是对第一个和最后一个控制点进行插值：

Wolfram Language code: pts = {{0, -1}, {1, 2}, {2, -2}, {3, 1}};
Wolfram Language code: Graphics[{BezierCurve[pts], Red, Point[{First[pts], Last[pts]}]}]

Bézier 曲线位于其控制点的凸包内：

Wolfram Language code: pts = {{0, -1}, {2, 1}, {4, -1}, {6, 1}, {4, 2}};
Wolfram Language code: hull = ConvexHullMesh[pts, MeshCellStyle -> {0 -> Red, 2 -> Opacity[1 / 4]}];
Wolfram Language code: Show[hull, Region[BezierCurve[pts, SplineDegree -> 4]]]

在三维空间中，具有共面控制点的贝塞尔曲线与其控制点位于同一平面内：

Wolfram Language code: pts = {{-3, -1, 0}, {6, 10, 0}, {-6, -10, 0}, {3, 1, 0}};
Wolfram Language code: pts//CoplanarPoints
Wolfram Language code: Graphics3D[{InfinitePlane[Take[pts, 3]], BezierCurve[pts]}, Lighting -> "Accent", ViewPoint -> #]& /@ {2{1, -1, 1}, Front, Top}

BezierFunction 给出 BezierCurve 上对应于特定参数值的位置：

Wolfram Language code: pts = {{-3, 0}, {6, 5}, {-6, -5}, {3, 0}};
Wolfram Language code: bfunc = BezierFunction[pts]
Wolfram Language code: positions = Table[bfunc[u], {u, 0, 1, 1 / 10}];
Wolfram Language code: Graphics[{BezierCurve[pts], StandardRed, PointSize[0.02], Point[positions]}]

Bézier 曲线可以通过使用 Bernstein 多项式对其控制点进行加权求和来构建：

Wolfram Language code: pts = {{0, -1}, {1, 1}, {2, -1}, {3, 1}};
Wolfram Language code: bezier[t_] := Sum[BernsteinBasis[3, i, t] * pts[[i + 1]], {i, 0, 3}]
Wolfram Language code: GraphicsRow[{ParametricPlot[bezier[t], {t, 0, 1}, Frame -> True, Axes -> False], Graphics[BezierCurve[pts], Frame -> True]}, ImageSize -> 400]

用 BernsteinBasis 来可视化曲线上每个控制点的权重：

Wolfram Language code: weights = Table[BernsteinBasis[3, i, t], {i, 0, 3}];
Wolfram Language code: Plot[weights, {t, 0, 1}, PlotLegends -> {"SubscriptBox[p, 1]", "SubscriptBox[p, 2]", "SubscriptBox[p, 3]", "SubscriptBox[p, 4]"}]

贝塞尔曲线具有仿射不变性：

Wolfram Language code: pts = {{0, -1}, {2, 2}, {4, -2}, {6, 1}};
Wolfram Language code: A = AffineTransform[{{{1, 1}, {0, 2}}, {1, 2}}];
Wolfram Language code: {Graphics[GeometricTransformation[BezierCurve[pts], A], Frame -> True], Graphics[BezierCurve[A[pts]], Frame -> True]}

对两条贝塞尔曲线的控制点进行平均，等同于对曲线本身进行平均：

Wolfram Language code: pts1 = {{0, -1}, {2, 1}, {4, 2}, {6, 2}}; pts2 = {{2, -1}, {3, 1}, {4, -1}, {6, 0}};
Wolfram Language code: Graphics[{Thick, RGBColor[0.4, 0.6, 1], BezierCurve[pts1], RGBColor[0.98, 0.56, 0.17], BezierCurve[pts2], RGBColor[0.93, 0.27, 0.27], BezierCurve[Mean[{pts1, pts2}]]}, Frame -> True]
Wolfram Language code: ParametricPlot[{BezierFunction[pts1][t], BezierFunction[pts2][t], Mean[{BezierFunction[pts1][t], BezierFunction[pts2][t]}]}, {t, 0, 1}, Frame -> True, Axes -> False, PlotStyle -> {RGBColor[0.4, 0.6, 1], RGBColor[0.98, 0.56, 0.17], RGBColor[0.93, 0.27, 0.27]}]

在两个线段的连接处，一个复合 Bézier 曲线可能不是平滑的：

Wolfram Language code: pts = {{0, 0}, {1, -1}, {3, -1}, {3, 0}, {4, 1}, {5, 1}, {6, 0}};
Wolfram Language code: Graphics[{BezierCurve[pts], Dashed, Gray, Line[pts], Red, Point[pts]}]

将边界附近的点设置为共线，以保证复合贝塞尔曲线的平滑性：

Wolfram Language code: pts[[5, 1]] = 3;
Wolfram Language code: Graphics[{BezierCurve[pts], Dashed, Gray, Line[pts], Red, Point[pts]}]

Bézier 曲线可被改为任意更高次数的等效曲线：

Wolfram Language code: pts = {{0, 0}, {2, 3}, {4, 0}};
Wolfram Language code: elevate[pts_] := With[...]
Wolfram Language code: epts = Table[Nest[elevate, pts, d], {d, 0, 3}];
Wolfram Language code: Graphics /@ Table[{BezierCurve[epts[[i]], SplineDegree -> i + 2], Dashed, Gray, Line[epts[[i]]], Red, Point[epts[[i]]]}, {i, Length[epts]}]

SubdivisionRegion 根据控制网格而非控制点生成平滑曲面：

Wolfram Language code: Region /@ {SubdivisionRegion[[image]], BezierCurve[IconizedObject[«[image]»]]}

互动范例  (2)

单个 Bézier 曲线编辑器：

Wolfram Language code: Column[{Manipulate[DynamicModule[{}, $curve = BezierCurve[pts, SplineDegree -> d, SplineClosed -> c]; Graphics[{$curve, Dashed, Opacity[0.5], Line[pts]}, PlotRange -> 5, Frame -> True, ImageSize -> 250]], {{pts, {{-4, -4}, {-3, 4}, {3, -4}, {4, 4}}}, Locator, LocatorAutoCreate -> True}, {{d, 3, "degree"}, 2, 6, 1}, {{c, False, "closed"}, {False, True}}], Button["Copy Curve to Clipboard", CopyToClipboard[$curve]]}]

在两个简单的贝塞尔曲线之间平滑插值：

Wolfram Language code: interpolateCurves[pts1_, pts2_] := Manipulate[Graphics[{BezierCurve[pts1(1 - t) + pts2 t], Opacity[0.25], Dashed, BezierCurve[pts1], BezierCurve[pts2]}], {t, 0, 1}]
Wolfram Language code: interpolateCurves[{...}, {...}]

两条符合曲线：

Wolfram Language code: interpolateCurves@@{{...}, {...}}

巧妙范例  (1)

由复合贝塞尔曲线构成的花朵：

Wolfram Language code: Graphics[BezierCurve[Table[{Cos[2k Pi / 13], Sin[2 k Pi / 13]}, {k, 0, 156, 4}]]]
Wolfram Research (2008)，BezierCurve，Wolfram 语言函数，https://reference.wolfram.com/language/ref/BezierCurve.html.

文本

Wolfram Research (2008)，BezierCurve，Wolfram 语言函数，https://reference.wolfram.com/language/ref/BezierCurve.html.

CMS

Wolfram 语言. 2008. "BezierCurve." Wolfram 语言与系统参考资料中心. Wolfram Research. https://reference.wolfram.com/language/ref/BezierCurve.html.

APA

Wolfram 语言. (2008). BezierCurve. Wolfram 语言与系统参考资料中心. 追溯自 https://reference.wolfram.com/language/ref/BezierCurve.html 年

BibTeX

@misc{reference.wolfram_2026_beziercurve, author="Wolfram Research", title="{BezierCurve}", year="2008", howpublished="\url{https://reference.wolfram.com/language/ref/BezierCurve.html}", note=[Accessed: 16-August-2026]}

BibLaTeX

@online{reference.wolfram_2026_beziercurve, organization={Wolfram Research}, title={BezierCurve}, year={2008}, url={https://reference.wolfram.com/language/ref/BezierCurve.html}, note=[Accessed: 16-August-2026]}
