CompleteGraph
CompleteGraph
n 個の頂点を持つ完全グラフ
を与える．
CompleteGraph[{n1,n2,…,nk}]
頂点数が n1+n2+⋯+nk の完全 k 部グラフ
を与える．
詳細とオプション
- CompleteGraphはユニバーサルグラフあるいは完全なグラフとしても知られている．
- CompleteGraphはGraphオブジェクトを生成する．
- CompleteGraph[n]は頂点数が n ですべての点と点の間に辺があるグラフを与える．
- CompleteGraph[{n1,n2,…,nk}]は頂点数が n1+⋯+nkの連結されていない複数の集合 Viに分割されたグラフを与える．この集合はそれぞれ ni個の頂点を持ち，異なる集合 Viと Vjの間では頂点がすべてが繋がれているが同一集合 Vi内の頂点は繋がれていない．
- CompleteGraph[…,DirectedEdges->True]は有向完全グラフを与える．
- CompleteGraphにはGraphと同じオプションが使える．
全オプションのリスト
例題
すべて開く すべて閉じる例 (4)
Table[CompleteGraph[i, PlotLabel -> Subscript[K, ``i``]], {i, 3, 6}]
Table[CompleteGraph[{i, i}, PlotLabel -> Subscript[K, i, i]], {i, 2, 4}]Table[CompleteGraph[n, DirectedEdges -> True, PlotLabel -> Subscript[K, n]], {n, 3, 5}]有向完全
部グラフは1つのグループから他のグループへ有向辺を使う：
Table[CompleteGraph[{i, i, i}, DirectedEdges -> True, PlotLabel -> Subscript[K, i, i, i]], {i, 2, 4}]オプション (81)
AnnotationRules (2)
DirectedEdges (2)
CompleteGraph[4]DirectedEdges->Trueを使って有向グラフを生成する：
CompleteGraph[4, DirectedEdges -> True]
Row[Table[CompleteGraph[Range[n], DirectedEdges -> True], {n, 2, 4}]]EdgeLabels (7)
CompleteGraph[4, EdgeLabels -> {12 -> "Hello"}]el = EdgeList[CompleteGraph[4]]CompleteGraph[4, EdgeLabels -> Table[el[[i]] -> Subscript["e", i], {i, Length[el]}]]CompleteGraph[4, EdgeLabels -> {24 -> [image], 34 -> [image], 13 -> [image]}]Placedを記号位置と一緒に使って辺に沿ったラベル位置を制御する：
Table[CompleteGraph[4, EdgeLabels -> {34 -> Placed["■■■", p]}, PlotLabel -> p], {p, {"Start", "Middle", "End"}}]Table[CompleteGraph[4, EdgeLabels -> {23 -> Placed["■■■", p]}, PlotLabel -> p, BaselinePosition -> Bottom], {p, {0, 1 / 4, 1 / 3}}]Table[CompleteGraph[4, EdgeLabels -> {23 -> Placed["■■■", {1 / 2, p}]}, PlotLabel -> p, BaselinePosition -> Bottom], {p, {{0, 0}, {1 / 2, 1 / 2}, {1, 1}}}]CompleteGraph[5, EdgeLabels -> {31 -> Placed[{"lbl1", "lbl2"}, {"Start", "End"}]}]CompleteGraph[5, EdgeLabels -> {31 -> Placed[{"lbl1", "lbl2", "lbl3"}, {"Start", "Middle", "End"}]}]TooltipとStatusAreaの値から自動でラベル付けを行う：
CompleteGraph[5, EdgeLabels -> Placed["Name", Tooltip]]CompleteGraph[5, EdgeLabels -> Placed["Name", StatusArea]]EdgeShapeFunction (6)
EdgeShapeFunctionの組込み設定のリストを得る：
ResourceData["EdgeShapeFunction"]CompleteGraph[4, EdgeShapeFunction -> "Line"]Table[CompleteGraph[4, EdgeShapeFunction -> {{ef, "ArrowSize" -> 0.1}}, PlotLabel -> ef], {ef, {"BoxLine", "DiamondLine", "DotLine"}}]Table[CompleteGraph[4, EdgeShapeFunction -> {{ef, "ArrowSize" -> 0.1}}, PlotLabel -> ef], {ef, ResourceData["EdgeShapeFunction", "FilledArrow"]}]Table[CompleteGraph[4, EdgeShapeFunction -> {{ef, "ArrowSize" -> 0.1}}, PlotLabel -> ef], {ef, ResourceData["EdgeShapeFunction", "UnfilledArrow"]}]Table[CompleteGraph[4, EdgeShapeFunction -> {{ef, "ArrowSize" -> 0.1}}, PlotLabel -> ef], {ef, ResourceData["EdgeShapeFunction", "CarvedArrow"]}]CompleteGraph[4, EdgeShapeFunction -> {12 -> "DotLine"}]CompleteGraph[5, EdgeShapeFunction -> {12 -> "BoxLine", "DotLine"}]ef[pts_List, e_] :=
Block[{s = 0.015, g = [image]}, {Arrowheads[{{s, 0.33, g}, {s, 0.67, g}}], Arrow[pts]}]CompleteGraph[4, EdgeShapeFunction -> ef]EdgeShapeFunctionはEdgeStyleと組み合せることができる：
CompleteGraph[4, EdgeStyle -> Blue, EdgeShapeFunction -> (Line[#1]&)]EdgeShapeFunctionはEdgeStyleより優先順位が高い：
CompleteGraph[4, EdgeStyle -> Blue, EdgeShapeFunction -> ({Red, Line[#1]}&)]EdgeStyle (2)
EdgeWeight (2)
CompleteGraph[4, EdgeWeight -> RandomInteger[5, 6]]WeightedAdjacencyMatrix[%]//MatrixFormCompleteGraph[4, EdgeWeight -> {a, b, c, d, e, f}]WeightedAdjacencyMatrix[%]//MatrixFormGraphHighlight (3)
CompleteGraph[4, VertexSize -> Tiny, GraphHighlight -> {1}]CompleteGraph[4, VertexSize -> Tiny, GraphHighlight -> {23}]CompleteGraph[4, VertexSize -> Tiny, GraphHighlight -> {1, 2, 13, 23}]GraphHighlightStyle (2)
GraphHighlightStyleの組込み設定のリストを得る：
ResourceData["GraphHighlightStyle"]GraphHighlightStyleの組込み設定を使う：
CompleteGraph[3, GraphHighlight -> {1, 23}, VertexSize -> Small, GraphHighlightStyle -> #, PlotLabel -> #]& /@ Select[ResourceData["GraphHighlightStyle"], # =!= Automatic&]GraphLayout (5)
CompleteGraph[5, GraphLayout -> Automatic]Table[CompleteGraph[20, GraphLayout -> l, PlotLabel -> l], {l, {"CircularEmbedding", "SpiralEmbedding"}}]Table[CompleteGraph[20, GraphLayout -> l, PlotLabel -> l], {l, {"SpringEmbedding", "SpringElectricalEmbedding", "HighDimensionalEmbedding"}}]VertexCoordinatesはGraphLayoutの座標を無効にする：
{CompleteGraph[5, GraphLayout -> "SpringElectricalEmbedding"],
CompleteGraph[5, GraphLayout -> "SpringElectricalEmbedding", VertexCoordinates -> Table[{i, i}, {i, 0, 4}]]}AbsoluteOptionsを使って，レイアウトアルゴリズムで計算されたVertexCoordinatesを抽出する：
CompleteGraph[5]AbsoluteOptions[%, VertexCoordinates]PlotTheme (4)
基本テーマ (2)
VertexCoordinates (3)
CompleteGraph[4]AbsoluteOptionsを使って結果の頂点座標を抽出する：
AbsoluteOptions[%, VertexCoordinates]ellipseLayout[n_, {a_, b_}] := Table[{a Cos[2Pi / n u], b Sin[2Pi / n u]}, {u, 1, n}]Graphics[Point[ellipseLayout[10, {2, 1}]]]CompleteGraph[10, VertexCoordinates -> ellipseLayout[10, {2, 1}]]VertexCoordinatesはGraphLayoutより優先順位が高い：
CompleteGraph[4, VertexCoordinates -> Table[{i, i}, {i, 4}], GraphLayout -> "CircularEmbedding"]VertexLabels (13)
CompleteGraph[3, VertexLabels -> "Name"]CompleteGraph[3, VertexLabels -> {1 -> "one"}]CompleteGraph[3, VertexLabels -> Table[i -> Subscript[v, i], {i, 3}]]CompleteGraph[3, VertexLabels -> {1 -> [image], 2 -> [image], 3 -> [image]}, ImagePadding -> 20]Placedを記号位置と一緒に使って外側の位置を含むラベルの置き方を制御する：
Table[CompleteGraph[3, VertexSize -> 0.1, VertexShapeFunction -> "Square", VertexLabels -> Table[i -> Placed["■■■", p], {i, 3}], PlotLabel -> p, ImagePadding -> 20], {p, {Before, After, Below, Above}}]pl = {{Before, Below}, {After, Below}, {Before, Above}, {After, Above}};Table[CompleteGraph[3, VertexSize -> 0.1, VertexShapeFunction -> "Square", ImagePadding -> 20, VertexLabels -> Table[i -> Placed["■■■", p], {i, 3}], PlotLabel -> p], {p, pl}]Table[CompleteGraph[3, VertexSize -> 0.25, VertexLabels -> Table[i -> Placed["■■■", p], {i, 3}], VertexShapeFunction -> "Square", PlotLabel -> p], {p, {Left, Top, Right, Bottom}}]pl = {{Left, Bottom}, {Right, Bottom}, {Left, Top}, {Right, Top}};Table[CompleteGraph[3, VertexSize -> 0.25, VertexShapeFunction -> "Square", VertexLabels -> Table[i -> Placed["■■■", p], {i, 3}], PlotLabel -> p], {p, pl}]Table[CompleteGraph[3, VertexSize -> 0.25, VertexShapeFunction -> "Square", VertexLabels -> Table[i -> Placed[[image], p], {i, 3}], PlotLabel -> p, BaselinePosition -> Bottom], {p, {{0, 0}, {1 / 2, 1 / 2}, {1, 1}}}]すべてのラベルを頂点の右上コーナーに置き，ラベル内の座標を変える：
Table[CompleteGraph[3, VertexSize -> 0.35, VertexShapeFunction -> "Square", VertexLabels -> Table[i -> Placed[[image], {{1, 1}, p}], {i, 3}], PlotLabel -> p, BaselinePosition -> Bottom], {p, {{0, 0}, {1 / 2, 1 / 2}, {1, 1}}}]CompleteGraph[3, VertexLabels -> {1 -> Placed[{"lbl1", "lbl2"}, {Above, Below}]}]CompleteGraph[3, VertexLabels -> {1 -> Placed[{"lbl1", "lbl2", "lbl3", "lbl4"}, {Above, After, Below, Before}]}]Placedの引数を使ってTooltipを含むフォーマットを制御する：
CompleteGraph[3, VertexLabels -> Placed["Name", Tooltip]]あるいはStatusAreaを含むフォーマットを制御する：
CompleteGraph[3, VertexLabels -> Placed["Name", StatusArea]]rotateLabel[lab_] := Rotate[lab, 45Degree]CompleteGraph[3, VertexLabels -> Table[i -> Placed["xxx", Below, rotateLabel], {i, 3}]]panelLabel[lab_] := Panel[lab, FrameMargins -> 0, Background -> StandardBlue]CompleteGraph[3, VertexLabels -> Table[i -> Placed["xxx", Center, panelLabel], {i, 3}]]hyperlinkLabel[lab_] := Hyperlink[lab, "http://www.wolfram.com"]CompleteGraph[3, VertexLabels -> Table[i -> Placed["xxx", Center, hyperlinkLabel], {i, 3}]]VertexShape (5)
Graphics，Image，Graphics3Dの任意のものを頂点の形として使う：
Table[CompleteGraph[5, VertexShape -> s, VertexSize -> Medium], {s, {[image], [image], [image]}}]CompleteGraph[5, VertexShape -> {2 -> [image]}, VertexSize -> Medium]VertexShapeはVertexSizeと組み合せることができる：
Table[CompleteGraph[5, VertexSize -> s, VertexShape -> [image], PlotLabel -> s], {s, {Small, Large}}]VertexShapeはVertexStyleの影響を受けない：
CompleteGraph[5, VertexSize -> 0.2, VertexShape -> [image], VertexStyle -> Blue]VertexShapeFunctionはVertexShapeよりも優先順位が高い：
CompleteGraph[5, VertexSize -> 0.1, VertexShapeFunction -> "Square", VertexShape -> [image]]VertexShapeFunction (10)
組込みのVertexShapeFunctionコレクションのリストを得る：
ResourceData["VertexShapeFunction"]"Basic"コレクションのVertexShapeFunctionの組込み設定を使う：
ResourceData["VertexShapeFunction", "Basic"]Table[CompleteGraph[4, VertexShapeFunction -> vf, VertexSize -> 0.2, PlotLabel -> vf], {vf, {"Triangle", "Square", "Rectangle", "Pentagon", "Hexagon", "Octagon"}}]Table[CompleteGraph[4, VertexShapeFunction -> vf, VertexSize -> 0.2, PlotLabel -> vf], {vf, {"DownTrapezoid", "UpTrapezoid", "Parallelogram", "FiveDown", "Circle", "Diamond", "Star", "Capsule"}}]"Rounded"コレクションのVertexShapeFunctionの組込み設定を使う：
ResourceData["VertexShapeFunction", "Rounded"]Table[CompleteGraph[4, VertexShapeFunction -> vf, VertexSize -> 0.2, PlotLabel -> vf], {vf, ResourceData["VertexShapeFunction", "Rounded"]}]"Concave"コレクションのVertexShapeFunctionの組込み設定を使う：
ResourceData["VertexShapeFunction", "Concave"]Table[CompleteGraph[4, VertexShapeFunction -> vf, VertexSize -> 0.2, PlotLabel -> vf], {vf, ResourceData["VertexShapeFunction", "Concave"]}]CompleteGraph[4, VertexShapeFunction -> { 1 -> "Square"}, VertexSize -> 0.2]CompleteGraph[4, VertexShapeFunction -> { 1 -> "Square", "Triangle"}, VertexSize -> 0.2]CompleteGraph[4, VertexShapeFunction -> (Inset[[image], #]&)]vf[{xc_, yc_}, name_, {w_, h_}] :=
Block[{xmin = xc - w, xmax = xc + w, ymin = yc - h, ymax = yc + h},
Polygon[{{xmin, ymin}, {xmax, ymax}, {xmin, ymax}, {xmax, ymin}}]
];CompleteGraph[4, VertexShapeFunction -> vf, VertexSize -> 0.2]VertexShapeFunctionはVertexStyleと組み合せることができる：
vf1[{xc_, yc_}, name_, {w_, h_}] := Rectangle[{xc - w, yc - h}, {xc + w, yc + h}]CompleteGraph[4, VertexSize -> 0.2, VertexStyle -> Blue, VertexShapeFunction -> vf1]VertexShapeFunctionはVertexStyleより優先順位が高い：
vf2[{xc_, yc_}, name_, {w_, h_}] := {Red, Rectangle[{xc - w, yc - h}, {xc + w, yc + h}]}CompleteGraph[4, VertexSize -> 0.2, VertexStyle -> Blue, VertexShapeFunction -> vf2]VertexShapeFunctionはVertexShapeと組み合せることができる：
CompleteGraph[4, VertexShapeFunction -> "Star", VertexSize -> {1 -> Small, Medium}]VertexShapeFunctionはVertexShapeより優先順位が高い：
CompleteGraph[4, VertexSize -> 0.3, VertexShapeFunction -> "Star", VertexShape -> [image]]VertexSize (8)
CompleteGraph[5, VertexSize -> Automatic]Table[CompleteGraph[5, VertexSize -> s, PlotLabel -> s], {s, {Tiny, Small, Medium, Large}}]Table[CompleteGraph[5, VertexSize -> s, PlotLabel -> s], {s, 0.1, 1, 0.3}]Table[CompleteGraph[5, VertexSize -> {"Scaled", s}, PlotLabel -> {"Scaled", s}], {s, 0.1, 1, 0.3}]
Table[CompleteGraph[5, VertexSize -> s, PlotLabel -> s], {s, {{0.1, 0.2}, {0.2, 0.1}}}]CompleteGraph[4, VertexSize -> {1 -> 0.2, 2 -> 0.3}]VertexSizeはVertexShapeFunctionと組み合せることができる：
Table[CompleteGraph[5, VertexSize -> s, VertexShapeFunction -> "Square", PlotLabel -> s], {s, {0.05, 0.1, 0.2}}]VertexSizeはVertexShapeと組み合せることができる：
Table[CompleteGraph[5, VertexSize -> s, VertexShape -> [image], PlotLabel -> s], {s, {0.1, 0.2, 0.4}}]VetexStyle (5)
Table[CompleteGraph[4, VertexStyle -> style, VertexSize -> 0.3, PlotLabel -> style], {style, {Yellow, EdgeForm[Dashed]}}]CompleteGraph[4, VertexStyle -> {1 -> Blue, 2 -> Red}, VertexSize -> 0.2]VertexShapeFunctionはVertexStyleと組み合せることができる：
vf1[{xc_, yc_}, name_, {w_, h_}] := Rectangle[{xc - w, yc - h}, {xc + w, yc + h}]CompleteGraph[4, VertexSize -> 0.2, VertexStyle -> Blue, VertexShapeFunction -> vf1]VertexShapeFunctionはVertexStyleよりも優先順位が高い：
vf2[{xc_, yc_}, name_, {w_, h_}] := {Red, Rectangle[{xc - w, yc - h}, {xc + w, yc + h}]}CompleteGraph[4, VertexSize -> 0.2, VertexStyle -> Blue, VertexShapeFunction -> vf2]VertexStyleはBaseStyleと組み合せることができる：
CompleteGraph[4, VertexStyle -> LightBlue, BaseStyle -> EdgeForm[Dotted], VertexSize -> 0.2]VertexStyleはBaseStyleより優先順位が高い：
CompleteGraph[4, VertexStyle -> LightBlue, BaseStyle -> Gray, VertexSize -> 0.2]VertexShapeはVertexStyleの影響を受けない：
CompleteGraph[5, VertexSize -> 0.2, VertexShape -> [image], VertexStyle -> Blue]VertexWeight (2)
アプリケーション (7)
完全グラフのGraphCenterにはすべての頂点が含まれる：
Table[HighlightGraph[#, GraphCenter[#]]&[CompleteGraph[i, VertexSize -> Small]], {i, 3, 6}]GraphPeripheryはすべての頂点を含む：
Table[HighlightGraph[#, GraphPeriphery[#]]&[CompleteGraph[i, VertexSize -> Small]], {i, 3, 6}]VertexEccentricityはすべての頂点について1である：
VertexEccentricity[CompleteGraph[5], #]& /@ VertexList[CompleteGraph[5]]FindVertexEccentricityPath[g_ ? UndirectedGraphQ, u_] /; MemberQ[VertexList[g], u] := Module[{d = GraphDistanceMatrix[g], posu, posv, vl = VertexList[g]}, posu = VertexIndex[g, u];
posv = First@First@Position[d[[posu]], Max[d[[posu]]]];
PathGraph[FindShortestPath[g, u, vl[[posv]]]]]Table[HighlightGraph[g = CompleteGraph[4], FindVertexEccentricityPath[g, u]], {u, Range[4]}]GraphRadiusは1である：
Table[GraphRadius[CompleteGraph[i]], {i, 3, 6}]FindRadiusPath[g_ ? UndirectedGraphQ] := Module[{c = First@GraphCenter[g], d, v, pos}, d = Table[GraphDistance[g, c, u], {u, VertexList[g]}];
pos = First@Position[d, Max[d]];
v = First@Part[VertexList[g], pos];
PathGraph[FindShortestPath[g, c, v]]]Table[HighlightGraph[#, FindRadiusPath[#]]&[CompleteGraph[i, VertexSize -> Small]], {i, 3, 6}]GraphDiameterは1である：
Table[GraphDiameter[CompleteGraph[i]], {i, 3, 6}]FindDiameterPath[g_ ? UndirectedGraphQ] := Module[{d = GraphDistanceMatrix[g], u, v, pos}, pos = First@Position[d, Max[d]];
{u, v} = Part[VertexList[g], pos];
PathGraph[FindShortestPath[g, u, v]]]Table[HighlightGraph[#, FindDiameterPath[#]]&[CompleteGraph[i, VertexSize -> Small]], {i, 3, 6}]
から
までの頂点連結性は
から
までの頂点独立経路の数である：
g = CompleteGraph[4, VertexLabels -> "Name"]{HighlightGraph[g, 12],
HighlightGraph[g, PathGraph[{1, 3, 2}]],
HighlightGraph[g, PathGraph[{1, 4, 2}]]}CompleteGraph[n]の頂点連結性は
である：
g = CompleteGraph[5, VertexLabels -> "Name"];{HighlightGraph[g, PathGraph[{1, 2}]],
HighlightGraph[g, PathGraph[{1, 3, 2}]],
HighlightGraph[g, PathGraph[{1, 4, 2}]],
HighlightGraph[g, PathGraph[{1, 5, 2}]]
}CompleteGraphの頂点次数をハイライトする：
HighlightCentrality[g_, cc_] := HighlightGraph[g, Table[Style[VertexList[g][[i]], ColorData["TemperatureMap"][cc[[i]] / Max[cc]]], {i, VertexCount[g]}]];g = CompleteGraph[8, VertexSize -> Large];HighlightCentrality[g, VertexDegree[g]]HighlightCentrality[g, ClosenessCentrality[g]]HighlightCentrality[g, EigenvectorCentrality[g]]特性と関係 (12)
CompleteGraph[n]の頂点の数：
VertexCount[CompleteGraph[n]]CompleteGraph[n]の辺の数：
EdgeCount[CompleteGraph[n]]
CompleteGraph[6]VertexDegree[%]g = CompleteGraph[8]HighlightGraph[g, h = Subgraph[g, Range[5]]]CompleteGraphQ[h]CompleteGraph[8, VertexSize -> {1 -> 0.2}]HighlightGraph[%, NeighborhoodGraph[%, 1]]CompleteGraph[5]Subgraph[%, First[FindClique[%]]]辺のない完全グラフのGraphComplement：
GraphComplement[CompleteGraph[5]]完全グラフでは，AdjacencyMatrixの対角の外側のすべての項は1である：
AdjacencyMatrix[CompleteGraph[25]]//MatrixPlot完全
部グラフでは，対角ブロックの外側の項はすべて1である：
AdjacencyMatrix[CompleteGraph[{1, 2, 3, 4, 5}]]//MatrixPlot
{CompleteGraph[3], CycleGraph[3]}
{CompleteGraph[4], WheelGraph[4]}
{CompleteGraph[6], LineGraph[StarGraph[7]]}おもしろい例題 (2)
Graphics[Table[Inset[CompleteGraph[RandomInteger[{4, 8}]], RandomReal[{0, 10}, 2], Automatic, 1], {75}]]ColoringCycles[n_] := Block[{i, e},
e = Table[Mod[#, n, 1]Mod[# + i, n, 1]& /@ Range[n], {i, (n - 1) / 2}];
HighlightGraph[CompleteGraph[n], Table[Style[e[[i]], ColorData[1][i]], {i, Length[e]}]]
]Table[ColoringCycles[i], {i, {3, 5, 7, 9, 11, 13}}]
